Quick Installation of the Fax Driver

System environment requirements

The following system environment is required to use the fax driver.

Item

Specifications

Operating system

Windows 7 Professional *

Windows 7 Enterprise *

Windows 8.1 *

Windows 8.1 Pro *

Windows 8.1 Enterprise *

Windows 10 Home *

Windows 10 Pro *

Windows 10 Enterprise *

Windows 10 Education *

Windows 11 Home

Windows 11 Pro

Windows 11 Enterprise

Windows 11 Education

Windows Server 2008 Standard *

Windows Server 2008 Enterprise *

Windows Server 2008 R2 Standard

Windows Server 2008 R2 Enterprise

Windows Server 2012 Datacenter

Windows Server 2012 Standard

Windows Server 2012 R2 Datacenter

Windows Server 2012 R2 Standard

Windows Server 2016 Datacenter

Windows Server 2016 Standard

Windows Server 2019 Datacenter

Windows Server 2019 Standard

Windows Server 2022 Datacenter

Windows Server 2022 Standard

* Supports the 32-bit (x86) or 64-bit (x64) environment.

CPU

Any processor of the same or higher specifications as recommended for your operating system

Memory

Memory capacity as recommended for your operating system

Sufficient available memory space is required for your operating system and the applications to be used.

Installing the fax driver on your computer

Install the fax driver on the PC by using the installer.

  • Administrator privileges are required to perform this task.

  • Before using a USB connection, connect this machine to the computer using a USB cable. If a wizard screen appears to add new hardware, click [Cancel].

  1. Insert the driver DVD into the DVD drive of the computer.

  2. Select the fax driver from the printer's installation menu.

    • Make sure that the installer starts, and then proceed to step 3.

    • If the installer does not start, open the driver folder on the DVD, double-click [UPDSetup.exe] (in the 32-bit environment) or [UPDSetup64.exe] (in the 64-bit environment), and proceed to step 3.

    • If the [User Account Control] window appears, click [Continue] or [Yes].

  3. Read the license agreement, then click [Agree].

  4. Click [Install (Network Search)] to detect devices on the network.

    • If you click [Install (Manual Setting)], you can manually set the printer.

  5. Select this machine from the list of detected printers.

    • If this machine is not detected, restart it. If this machine is not detected even after restart, return to step 4 and click [Install (Manual Setting)]. Click [Add to list], and manually set the printer.

    • If multiple same models are displayed, check with the IP address. You can check the IP address of this machine in the screen that is displayed by tapping [Utility] - [Device Information].

    • If you click [Refresh], you can search the device again.

    • If you click [Search Settings...], you can specify detailed search conditions and search for the device.

    • If there is a port corresponding to the IP address of the device, delete it in advance.

  6. Click [Details] as needed, and change the default print settings.

    • [Print Queue Name] (Printer name): Automatically set from the information of the device selected in the list.

    • [Port]: Set the port used for the printer.

    • [Model]: The model corresponding to the device selected in the list is selected automatically.

    • [Printer Driver Name]: The driver corresponding to the device selected in the list is selected automatically.

    • [Share Setting and Share Name.]: When sharing the printer, select the [Share this print queue.] check box and enter the share name.

    • [Admin Settings]: Allows you to change the default print settings.

  7. Click [Next].

  8. Check the items to be installed, and click [Install].

  9. After installation was completed, configure initial settings for the fax driver.

    • For details on the initial settings for the fax driver, refer to Here.

  • Updating the printer driver (Here)
